BARREL NIPPLE THREAD STANDARD NPT, BSPT, BSP
Pressure Manhole designed for secure access to pressurised tanks and vessels. Featuring a hand wheel-operated clamping system, it provides convenient opening and closing with a pressure rating of 1–8 bar.
Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock Out of stock
₹10,000.00 ₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
₹10,000.00
Size
Select Size
Share :
Product Details
The Pressure Manhole is designed for providing secure and convenient access to pressurized tanks, vessels, and industrial process equipment. Its robust construction and multi-point handwheel clamping arrangement help ensure a secure closure during pressure applications.
The handwheel-operated design makes the manhole convenient to open and close during inspection, cleaning, maintenance, and servicing activities. Available in multiple standard sizes, it can be selected according to the tank or vessel access requirements.
Key Features
- Designed for pressurized tanks and vessels
- Pressure rating: 1–8 bar
- Handwheel-operated clamping mechanism
- Multi-point clamping for secure closure
- Convenient access for inspection and maintenance
- Available in multiple standard sizes
- Suitable for industrial tank and process applications
Available Specifications
| Size | OD (mm) | t (mm) | H (mm) | t1 (mm) | Handwheel Qty. | Pressure (Bar) |
|---|---|---|---|---|---|---|
| 350 | 356 | 4 | 100 | 3 | 4 | 1–8 |
| 400 | 406 | 4 | 100 | 3 | 5 | 1–8 |
| 430 | 436 | 4 | 100 | 3 | 6 | 1–8 |
| 450 | 456 | 4 | 100 | 3 | 6 | 1–8 |
| 500 | 506 | 4 | 100 | 3 | 8 | 1–8 |
| 600 | 608 | 4 | 100 | 4 | 10 | 1–8 |
Applications: Pressure tanks, process vessels, industrial storage tanks, and equipment requiring secure access under controlled pressure conditions.
