The Swing Manhole with Two Intersectant Arms is designed to provide convenient access to tanks, vessels, and process equipment. The two intersectant swing arms allow the manhole assembly to be opened and positioned conveniently, making inspection, cleaning, and maintenance easier.
The robust circular design incorporates multiple clamps around the manhole for secure closure. It is suitable for applications where reliable tank access and controlled sealing are required. The product is available in DN450 configuration with different outlet/connection dimensions as specified below.
Key Features
- Swing-type manhole design with two intersectant arms
- Convenient opening and closing mechanism
- Secure multi-point clamping arrangement
- Suitable for tank inspection, cleaning, and maintenance
- Designed for industrial tanks and process vessels
- Pressure rating: 1–4 bar
- Available in different dimensional configurations
Available Specifications
| Size | OD (mm) | OD L1 (mm) | t (mm) | t (mm) | H (mm) | t1 (mm) | Pressure (Bar) |
|---|
| DN450 | 450 | 50.8 | 6 | 4 | 160 | 318 | 1–4 |
| DN450 | 450 | 102 | 6 | 4 | 160 | 284 | 1–4 |
Applications: Industrial storage tanks, process vessels, mixing tanks, and other equipment requiring convenient and secure access for inspection and maintenance.
